Elektra Weidezaungeräte Compact B 180, battery device, without battery

Compact B 180, battery device low-priced 9 Volt device

• powerful
• with switch and fence control
• good value

Technical data compact B 180

operating voltage: 9 V

Open-circuit voltage: approx. 6000 V

Voltage at animal contact: approx. 2500 V

Voltage at 500 Ohm (short circuit): approx. 1100 V

Pulse energy: approx. 0.15 J

Power consumption: approx. 18 mA

max. fence length (CEE): approx. 5 km

rec. Fence length (depending on vegetation): approx. 1-3 km

Recommendation for use of Compact B180 battery unit

Battery devices are the optimal choice when there is no possibility to connect to the mains and the higher power of a battery device is not required. Typical areas of application are portion pastures, paddocks and herding small animals in the yard and garden. Depending on the design, soil conditions and vegetation, the possible fence lengths vary between one and eight kilometres. Switchable power levels not only allow optimum adaptation to different herding conditions, but also enable particularly economical operation.
